OBS: Begrenset antall
High Output:
Type: High output moving coil cartridge with flux damper and softened magnetism
Output Voltage: 2.8 mV (at 1KHz, 5cm/sec.)
Channel Separation: 25 dB (at 1KHz)
Channel balance: 1.0 dB (at 1KHz)
Frequency response: 20 - 20,000 Hz(±2dB)
Compliance: 12 mm/N
Tracking force: 1.8 - 2.2 g
Impedance: 150 ohms
Recommended load impedance: > 1,000 ohms
Cantilever: 6mm length hardened aluminium pipe
Stylus tip: Nude Diamond "Shibata III" Line Contact
Weight: 7.5 g
Low Output:
Type: Low output moving coil cartridge with flux damper and softened magnetism
Output Voltage: 0,5 mV (at 1KHz, 5cm/sec.)
Channel Separation: 25 dB (at 1KHz)
Channel balance: 1.0 dB (at 1KHz)
Frequency response: 20 - 20,000 Hz(±2dB)
Compliance: 12 mm/N
Tracking force: 1.8 - 2.2 g
Impedance: 32 ohms
Recommended load impedance: > 100 ohms
Cantilever: 6mm length hardened aluminium pipe
Stylus tip: Nude Diamond "Shibata III" Line Contact
Weight: 7.5 g
